Introduction to THDPM-1
|
Documents- ->THDPM-1 Catalog Product Videos:
->Introduction to DTM-1 ->Introduction of PT-AC ->Introduction to SMART-QC ->Introduction to PRPT-16 |
||||||||
The above video shows the function of the old model of THDPM-1. For a new model of THDPM-1 video will update soon.
Harmonic Analysis up to 55th Harmonic with Bar Graph: Part 1. Showing on Display
Harmonic Analysis up to 55th Harmonic with Bar Graph: Part 2. Showing Pdf on Display
THDPM-1 Data Logging Sample File
THDPM-1 Data Logging Sample File with SMARTQC Data
We have updated some features in THDPM-1:
1. New and elegant looking Enclosure
2. More buttons and new display for Hold/status
3. Pen Drive up to 16GB ( No requirement of Computer)
4. Internal onboard memory up to 32000 tests
5. Software Interfacing facility
6. Log-On-Connect. In production Mode, if the user connects a new Load, it automatically logs to Pen Drive. When he disconnects, it increments the Serial no for next.
Click here to go THDPM-1 log on connecting mode, 5W bulb harmonic testing report, THDPM-1 Test report
